Cassette Air conditioner Nippon NCD-24HRFNX-Q + NOCA30U-24HFN8-Q

  • Code: 2560441
  • In stock
  • Weight: 87.80 kg

1344.71 EUR (VAT incl.)

Documents

  • Energy label for Nippon NCD-24HRFNX-Q / NOCA30U-24HFN8-Q Download

Comments

  1. Add comment
  2. 1 2 3 4 5

Technical information

  • Basic
  • Cooling capacity (Min./Nom./Max):

    3.22 / 7.03 / 8.21 kW

  • Heating capacity (Min./Nom./Max):

    2.43 / 7.62 / 8.65 kW

  • Consumption power - cooling (Min./Nom./Max):

    0.48 / 2.19 / 2.85 kW

  • Consumption power - heating (Min./Nom./Max):

    0.5 / 2.05 / 2.88 kW

  • Capacity (BTU):

    24 000 BTU

  • Seasonal efficiency SEER cooling:

    6.1

  • SCOP:

    4

  • Energy label (Cooling / Heating) - Average climate:

    A++ / A+

  • Operation Range (Cooling):

    -15 ~ 50 °C

  • Operation Range (Heating):

    -15 ~ 24 °C

  • Suitable for rooms up to:

    47 square meters

  • Warranty:

    24 months

  • Refrigerant:

    R-32

  • Power supply (Phase/Frequency/Voltage):

    1~/50/220-240

  • Indoor unit
  • Dimensions:

    840 x 840 x 245 H x W x L (mm)

  • Weight:

    23 kg

  • Sound Pressure - cooling (High/Nom./Low/Silent):

    47 / 43 / 40 / - dB

  • Sound Pressure - heating (High/Nom./Low/Silent):

    47 / 43 / 40 / - dB

  • Outdoor unit
  • Compressor type:

    Rotary

  • Dimensions:

    702 x 845 x 363 H x W x L (mm)

  • Weight:

    50 kg

  • Refrigerant piping - Liquid / Gas:

    9.52 / 15.9 mm (3/8" / 5/8") mm / inch

  • Sound Pressure - cooling (High/Nom./Low/Silent):

    62 / - / - / - dB

  • Sound Pressure - heating (High/Nom./Low/Silent):

    62 / - / - / - dB

  • Shipping package - NIPPON NCD-90P-Q PANNEL 24-60
  • Packages quantity:

    1 pc.

  • Package dimensions (HxWxD cm):

    9 x 104 x 104; Weight: 8 kg.;

  • Shipping package - NIPPON NOCA30U-24HFN8-Q PRO OU
  • Packages quantity:

    1 pc.

  • Package dimensions (HxWxD cm):

    76 x 40 x 97; Weight: 52.8 kg.;
